Product Features:
1,Special 48V for Track magnet lamp
2,Stable electronic operation
3,long life span
4,Higher efficiency
5,Lower temperature
6,High quality components:
IC brand ON SEMI(orginal USA) MOSFET brand TOSHIBA (Original JAPAN)
Product Description
| SBV-60-12/24/48 | SBV-100-12/24/48 | SBV-150-12/24/48 | SBV-200-12/24/48 | SBV-250-12/24/48 | SBV-300-12/24/48 | ||||||
| 130*55*22 | 150*55*22 | 200*55*22 | 280*55*22 | 280*55*22 | 300*55*22 | ||||||
| >0.5 | >0.5 | >0.5 | >0.5 | >0.5 | >0.5 | ||||||
| IP 20 | IP 20 | IP 20 | IP 20 | IP 20 | IP 20 | ||||||
| 12V/24V | 12V/24V | 12V/24V | 12V/24V | 12V/24V | 12V/24V | ||||||
| 60 W | 100 W | 150 W | 200 W | 250 W | 300 W | ||||||
| 5.00 A(12V) | 8.33 A(12V) | 12.50 A(12V) | 16.66 A(12V) | 20.83 A(12V) | 25.00 A(12V) | ||||||
| 2.50 A(24V) | 4.16 A(24V) | 6.25 A(24V) | 8.33 A(24V) | 10.41 A(24V) | 12.50 A(24V) | ||||||
| 1.25 A(48V) | 2.08 A(48V) | 3.125 A(48V) | 4.16 A(48V) | 5.21 A(48V) | 6.25 A(48V) | ||||||
| ≤200MV | ≤200MV | ≤200MV | ≤200MV | ≤200MV | ≤200MV | ||||||
| 180 -264 V | 180 -264 V | 180 -264 V | 180 -264 V | 180 -264 V | 180 -264 V | ||||||
| 85% | 87% | 87% | 87% | 87% | 87% | ||||||
| COLD START 冷启动 <60A/230VAC | |||||||||||
| <2mA 230VAC | |||||||||||
| 110-150% rated output power.额定输出功率的110-150% | |||||||||||
| Protection type:Hiccup mode recover automatically,打嗝模式,自恢复 | |||||||||||
| When the output of positive and negative poles are short-circuited, the power supply is automatically locked 输出正负极短路时，电源自动锁死 | |||||||||||
| 13.8-16.2V (12V) / 27.6-32.4V (24V) | |||||||||||
| Protection type:Shut down o/p voltage，关断输出电压，重启恢复 | |||||||||||
| Protection type:Shut down o/p voltage，关断输出电压，重启恢复 | |||||||||||
| -30～+60℃ | |||||||||||
| 20-80% RH non-condensing 无冷凝 | |||||||||||
| 10-90% RH non-condensing 无冷凝，-40～+85℃ | |||||||||||
| 10-500Hz,2G 10min/1cycle,period for 60min.each along X,Y,Z axes | |||||||||||
| 10-500Hz,2G 10分钟/周期 X,Y,Z 轴各60分钟 | |||||||||||
| III,Compliance to EN61558,EN50178,EN60664-1,EN62477-1 | |||||||||||
| Compliance to EN60950-1,EN60335-1,EN61558-1/-2-16 | |||||||||||
| I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC | |||||||||||
| Compliance to EN55015,Class B,EN55014,EN61000-3-2,-3 | |||||||||||
| Compliance to EN61000-4-2,3,4,5,6,8,11, EN61000-6-2(EN50082-2) | |||||||||||
